HD/e stands for heavy duty and electric and the frame is built stiffer, stronger, and longer.
The complete bike includes:
Jones Plus LWB HD/e Frameset.
Wheels with 50 mm wide rims, 36 spokes, Schrader valve stems.
Big 29” 29" x 2.8" smooth tires.
BB7 disk brakes with 203 mm rotors front and rear.
1 x 12 speed drivetrain with a single click shifter.
Steel chainring, cassette teeth, axles, and hub driver body.
Bigger seat with deeper padding and chromoly rails.
And more!
The Jones Plus LWB HD/e is based on the Jones Plus LWB, a design that has proven itself as one of the most versatile bikes around, winning awards for its abilities as a bikepacking bike, as well as praise for just about all other types of riding. Combine this with Jones Geometry, the upright riding position, big 29” 36 spoke wheels and plus size tires, drivetrain and brake parts selected for strength and durability, and we have a heavy duty bicycle that is efficient and comfortable!
The Jones Plus LWB HD/e frames and unicrown forks are made from heat treated 4130 chromoly steel and have a great feel to them that is stiffer, stronger and with a little more weight than the non HD/e version (~ 300 grams).
Perfect for heavy loads or an ebike conversion. If you’re in need of a heavy duty bike for loaded touring, bikepacking, mountain biking, commuting, gravel or road riding, the Jones Plus HD/e has you covered!
Features and Benefits
Jones Plus LWB HD/e Geometry for a great ride in a wide range of conditions.
Frame and fork designed to work together, a frameset.
Frame is compatible with Jones Truss Fork for Plus LWB
These steel frames have a great feel that is stiffer, stronger and with a little more weight, ~ 300 grams. Perfect for heavy loads.
Super tough heat treated 4130 chromoly steel frame and fork with butted tubing.
Longer chainstays, 20", provide a longer wheelbase with more stability, smoother ride, keeps the front end down on steep climbs. It also creates more chainring clearance and room for a center kickstand mount.
Big and tall Jones Spec. wheelset with 29" x 3.25"/700c x 82 mm tubeless ready knobby tires, or 29" x 2.8"/700c x 71 mm tubeless ready smooth tires on 50 mm wide rims allow you to run very low pressure for maximum suppleness, better traction, more flotation and comfort along with lower rolling resistance, less flats and more safety, on or off road!
36 spokes for ultimate strength and durability.
Schrader (automotive type) valves are easier to use and are more durable. More airflow for easier tubeless set up.
Big tire clearance.
Jones 710 mm Loop H-Bar and H-Grips.
Wide range 11 - 50 SRAM SX 1 x 12 drivetrain.
Single click shifter for quiet, reliable shifting with greater durability.
Mechanical disk brakes with large 203 mm rotors front and rear for more power and better cooling.
Multiple rear rack and fender braze-on mounts for the best rack/fender/tire size fit, or for mounting water bottles. The fork can hold two more water bottles.
Bosses located at top of seat stays for ease of mounting racks.
Chain: SRAM SX Eagle 12 speed
